The new designs incorporate cluster management technology, whereas the LEDs are fixed onto PCB boards forming clusters which are then welded together and extruded in a food grade silicone to form the actual strip lighting, these PCB boards are connected in parallel with the electrical circuit working together in synergy as a lighting platform, but independently in the unlikely case of failure, this means if there is a failure on any components of the lighting it would be isolated and not affect the remaining lighting system.
Plug and play system
Conventional lighting requires separate power and a wired connection to every lamp, needing the expertise of electricians. This becomes labour-intensive and costly when running many meters of lighting. The BRANDO LED Strip Lighting plugs into an existing power source using a power supply which then connects to one end of the LED strip. A single power supply will light a 20 meter LED section. To extend beyond 20 meters, just add another power supply at the other end and connect the next section of LED strip – it's that simple.
Maintenance-free. Easy to repair.
Damage to lighting through routine underground activities happens. When a conventional lamp is damaged, it results in loss of illumination over many meters – making the affected area a safety hazard until repaired by a qualified electrician. Should a section of the BRANDO strip light be damaged, only this section loses light. The remaining portion of the strip continues to provide illumination – allowing for a safer environment. Additionally, damaged sections can be replaced in 8" strips – making it a quick and cost-effective fix.
• Intelligent temperature management, sensors monitor LED temperature and if safe parameters are exceeded the affected LED’s are automatically dimmed until safe temperatures are restored.
• Intelligent voltage surge management, restorable resistors limit overcurrent and overvoltage situations.
• AC to DC convertors, miniature voltage convertors.
• Short circuit protection, in the case of short circuit the power is isolated until the circuit is normalized.
Dimension: 10000mm(length） *20mm(width） *10mm(height）
| Part Number | BO-SL60-36V(A) GREEN |
| LED Chip | Epistar |
| LED configuration | 72 LED's spaced evenly over a metre length |
| Range fed from both sides | 40 metres |
| Recommended fixing height | 5 - 6 Metres |
| IP Rating | 68 |
| Power Consumption per LED | 0.16 Watts |
| Power Consumption per Metre | 12 Watts |
| Colour Rendering Index CRI | > 80 |
| Colour temperature | 6500 Kelvin |
| Luminous Efficacy | 80 Lumens / Watt |
| Voltage on lighting VDC | 36 VDC |
| Supply voltage for power controllers VAC | 85 - 265 VAC |
| Light maintenance | 15%-20% Drop over 4 years |
| Lifespan | 5 Years + |
| Warranty Lighting | 3 Years |
| Outer covering | Food grade silicone |
| Dimensions | 10000mm(length） *20mm(width） *10mm(height） |
| Tensile strength | +-50KG |
| Operating temperature | -40℃ to 120℃ |
| Protection | Short Circuit Over Voltage Over temperature Over Current |
